Segregated Slotted Cable Tray Divider Design for Power Signal Cable Isolation

This segregated slotted cable tray uses an internal divider to keep power and signal cables apart in the same run. The folded metal sheet body keeps its structural toughness and joint locking strength, so the slotted cable tray stays rigid while separating cables of very different duty.

Working as a cable support tray and slotted cable trunking, it organises sensitive data and instrument lines away from power feeders, from a single signal circuit to a full plant network. Surface film coating adds heat and corrosion protection, and customized logo printing is available for identification.

• Segregated Divider Routing
  An internal divider splits the tray into separate lanes. Power and signal cables stay apart, lowering crosstalk and improving signal quality.
• Power Signal Isolation Design
  Physical separation limits interference between voltage levels. Sensitive control and data cables run safer beside power feeders in the same tray.
• Adjustable Divider Position
  The divider can be moved or added during installation. Route layout adapts easily when cable counts or types change over time.
• Shared Trunking Saving
  One divided tray replaces two separate runs. This saves on brackets, supports and space inside congested cable corridors.

Segregated slotted cable trays are common in substations, control rooms, data halls and process plants. This divided cable support tray and slotted cable trunking keep power and signal cabling isolated yet tidy inside one shared route.
